KB2 K3S Yagi antenna 3 elements 14-21-28MHz PEP: 1.5KW

Ref: K3S

Immediately available
€683.00
€580.55 Save 15%
Tax included
rating No review at the moment
Usually ships within 24 hours.
Quantity

Guarantee safe & secure checkout

You can purchase this product in installments with Sella Personal Credit. Click here for more information.


KB2 K3S 3-element directive antenna for 10-15-20 metres

Antenna of excellent workmanship and with quality materials.

Also included in the package is its 1.5 KW 1:1 balun

Download the assembly and features manual on "Attached Documents".

Comparison table between the two antennas, 2 elements and 3 elements.

KB2/K3S KB2/K3S-2
Frequency 14/21/28MHZ 14/21/28MHZ Frequency 14/21/28MHZ 14/21/28MHZ
Element 3 Element 2
DBD 8 DBD 3.6
DB 25 DB 20
SWR 1.5:1 1.5:1 SWR 1.5:1 1.5:1
Power rating CW500W,SSB1KW Power rating CW500W,SSB1KW
Main beam length 4.3M Main beam length 2.4M
Bit length (longest unit) 8.4M Bit length (longest unit) 8.4M
Turning radius 4.8M Turning radius 4.2M
Weight 17KG Weight 9KG
Wind load 10 level<10 Wind load 10 level<10

K3S
3 Items

Data sheet

Guy
YAGI 3 ELEM.
Specifications
10-15-20 metri
Compatible brand
Generico
Sub-Categories
HF Direttive

Specific References

MPN
K3S
