Diamond A-144S5R2 - 144MHz 5-element directive antenna

Ref: A144S5R2

Immediately available
€42.80
Tax included
rating Read the 4 reviews
Average rating: 5/5 Number of reviews: 4
Usually ships within 24 hours.

Quantity

Guarantee safe & secure checkout

A-144S5R2

5 element directive antenna for 144MHz

Technical features:

model
(frequency)
A-144S5
144-146
A-144S10R
144-146
A-1430S7
144+430Mz

A-430S10
430-440

A-430S15
430-440

Elements 5 10 3 (144) + 5 (430) 10 15
Gain (dBi) 9.1 11.6 7.5 (144) 9.3 (430) 13.1 14.8
Max power (Watt) 50 50 100 50 50
Impedance (Ω) 50 50 50 50 50
VSWR 1.3:1 1.3:1 inf 1.5:1 1.4:1 1.4:1
Weight kg) 0.63 1.1 0.950 0.64 0.97
Dimensions (mm) 950 x 1090 2130 x 1090 1250 x 1020 1190 x 370 2245 x 370
Mast diameter (mm) 25~47 25~47 25-62 25~47 25~47
Connector MJ MJ MJ MJ MJ
F/B (dB) =< 14 < 15 ≤ 11.5 (144)
≤ 8 (430)
< 15 < 14
Surface
A144S5R2

Data sheet

Mpn
A144S5R2
Guy
VHF/UHF/SHF Base
Compatible brand
Generico
Sub-Categories
VHF/UHF/SHF Base

Specific References

ean13
0644730931311
Filter reviews
(4)
(0)
(0)
(0)
(0)
(0)
Reset

Antenna 5 el
rating 5
Prodotto eccellente corrispondente a pieno alle mie esigenze, Ben curata la confezione .
Antenna ok, adatta anche in portatile
rating 5
Ho preso questa antenna per attivazioni radio e contest in portatile, molto pratica e leggera, si monta in poco tempo ed ha un\'ottima resa.
144x5 elementi
rating 5
Che cosa dire, ottimo prodotto
ordine
rating 5
Prodotto di qualità e conforme alle aspettative
