Ref: AH710
Out-of-Stock2-30 MHz wide band HF antenna for civil and military uses
ICOM AH-710 FOLDED DIPOLE ANTENNA
Broadband antenna for military and civil uses
Operational range: 2 to 30 MHz
Equipped with coaxial cable (length: 30 meters) headed with PL-259 connector at both ends
Length: 24.5 meters
Weight: 3.1kg.
Max applicable power: 150W
Impedance: 50 Ohms
ROS:
< 2.0 : 1 (1.9 to 18 MHz)
< 2.5 : 1 (18 to 30 MHz)
Connector: SO-239
Data sheet
