ECO ANTENNAS LW-20 QRO long wire end fed from 80 to 6 meters

ECO ANTENNAS LW-20 QRO long wire end fed from 80 to 6 meters

The LW-20 are end-fed long wire antennas. They have a 9:1 UNUN at the feed point which allows powering directly with 50 Ohm coaxial cable. THE UNUN 9:1 also removes static noise and provides a DC path to ground. Everyone is capable of handling up to 400W RF.
With 20m length, it will work on all bands from 80m to 6m via an ATU. Great performance with small footprint.

These antennas give excellent results where space is vital. However, Please note that due to the variable impedance characteristic of any long wire antenna, the ATU built into the average transceiver will not be can handle all bands. For full coverage you will need a External ATU or in any case a system capable of capacitively loading the je X of the antenna. This result can be obtained with chord networks in an L-shaped configuration to T.

The LW-20 is fully assembled and ready to use. Even the thread poly weave does not tangle and is extremely durable.

Specifications:

Type: END-FED wire antenna

Frequency: 3.5 - 52 MHz
Band: 80-6m
Potenza: 1 KW PeP (FT*, RTTY, ETCC..) 200 WATTS
Impedance 50 Ohm
SO-239 connector
Length 20.28 meters
Non-Kink Poly Weave Wire
