Ref: PST152VC
Shipped in a few daysPST-152VC
Multiband vertical antenna trapped 10-15-20m, with loaded rigid radials.
- Max rigid radial length = 2m
- Useful bandwidth :
- 20m = approximately 250Kc/s
- 15m = total coverage
- 10m = approximately 800Kc/s
- RF shock for electrostatic protection;
- 2KW pep
- Connector : SO239
TECHNICAL SPECIFICATIONS:
Height: approximately 4m;
Max loaded radial length: 2m;
Weight: 4Kg;
Wind area: 0.09m2;
Max wind: 130km/h;
Accepts mast: 40-50mm (60mm on request);
6060T6 aluminum bracket and stainless steel bolts
Data sheet
