KB2 K3S-2 Yag antenna 23 elements bands 20/15/10
KB2 K3S-2 Yag antenna 23 elements bands 20/15/10
    KB2 K3S-2 Yag antenna 23 elements bands 20/15/10
    KB2 K3S-2 Yag antenna 23 elements bands 20/15/10

KB2 K3S-2 Yag antenna 23 elements bands 20/15/10

Ref: K3S-2

Immediately available
€554.00
€470.90 Save 15%
Tax included
rating Read the review
Average rating: 5/5 Number of reviews: 1
Usually ships within 24 hours.
Quantity

Guarantee safe & secure checkout

You can purchase this product in installments with Sella Personal Credit. Click here for more information.


  • Description
  • Product Details
  • Attachments
  • Comments

  • Warning: file_exists(): open_basedir restriction in effect. File(/views/templates/hook/tab.tpl) is not within the allowed path(s): (/home/fhamradi/:/opt/cpanel/ea-php81/root/usr:/usr/local/lib/php:/tmp:/etc/pki/tls/certs/ca-bundle.crt:/var/cpanel/php/sessions:/usr/local/bin/wp) in /home/fhamradi/public_html/classes/module/Module.php on line 2292
    Reviews

KB2 K3S 2-element directive antenna for 10-15-20 meters

Antenna of excellent workmanship and with quality materials.

Also included in the package is its 1.5 KW 1:1 balun

Download the assembly and features manual on "Attached Documents".

Comparison table between the two antennas, 2 elements and 3 elements.

KB2/K3S KB2/K3S-2
Frequency 14/21/28MHZ 14/21/28MHZ Frequency 14/21/28MHZ 14/21/28MHZ
Element 3 Element 2
DBD 8 DBD 3.6
DB 25 DB 20
SWR 1.5:1 1.5:1 SWR 1.5:1 1.5:1
Power rating CW500W,SSB1KW Power rating CW500W,SSB1KW
Main beam length 4.3M Main beam length 2.4M
Bit length (longest unit) 8.4M Bit length (longest unit) 8.4M
Turning radius 4.8M Turning radius 4.2M
Weight 17KG Weight 9KG
Wind load 10 level<10 Wind load 10 level<10

K3S-2
1 Item

Data sheet

Mpn
KB2 K3S-2
Guy
YAGI 2 ELEM.
Compatible brand
Generico
Sub-Categories
HF Direttive
New
Yagi 2 elementi KB2 K3s
rating 5
Ottima fattura, montaggio semplice così anche la calibrazione per i 20 e 15 metri, un po\' meno per i 10 MT causa anche perché non ho potuto installarla a più di 5.5 metri dal piano del tetto, in pochi giorni ho già collegato una buona parte del mondo
