12JXX2 144MHz directive antenna

Ref: 12JXX2

Immediately available
€294.00
Tax included
rating Read the review
Average rating: 5/5 Number of reviews: 1
Usually ships within 24 hours.

Quantity

Guarantee safe & secure checkout

You can purchase this product in installments with Sella Personal Credit. Click here for more information.


12JXX2 12 element directive antenna 144MHz

SPECIFICATIONS:

- Frequency : 144 MHz;

- Elements : 12;

- Gain : 12.67 dBd / 14.81 dBi;

- F/R ratio : 30 dB;

- Angle at -3 dB plane E - H : 33.6? - 36.4?;

- E - H plane spacing : 3.59 - 3.33 m;

- ROS .: 1:1.2;

- Boom length : 5.6 m - 2.69 lambda;

- Boom diameter : 25 - 30 - 25;

- Element diameter : 5;

- Dipole : T-match;

- Connector : N precision;

- Balun : RG 142;

- Applicable power: 1000 W;

- Mast Attack : max 75 mm;

- Weight : 4 kg;

- Area to the wind : 0.2 m

12JXX2
9 Items

Data sheet

Mpn
12JXX2
Guy
VHF/UHF/SHF Base
Compatible brand
Generico
Sub-Categories
VHF/UHF/SHF Base

Specific References

ean13
0644730926744
Professionalità e cortesia
rating 5
Sono sempre molto soddisfatto degli acquisti in questo negozio che è una realtà di riferimento per noi OM italiani
