Ref: MINIMAG27
Immediately availableElectrical Data:
Type: Center-loaded
Radiation: Omnidirectional
Frequency band: 27 … 27.5 MHz Adjustable
Systems: CB 27MHz
Bandwidth: ≥ 280KHz @ VSWR ≤ 2
Maximum power: 10 Watts (CW) continuous 50 Watts (CW) for short time
Cable length / type: 3 m (9.84 ft) / RG58
Connector: UHF-male (PL-259)
Mechanical Data: Materials:
Copper, Brass, Stainless Steel, Fiberglass
Height (approx): 630 mm / 2.07 ft
Weight (approx): 575 gr / 1.27 lb
Mounting type: With magnetic base
