Ref: PS30swII
Immediately availablePS-30 SWII
30A Switching Power Supply
NISSEI PS-30SWII was designed for use with amateur radio equipment.
Ideal for the most demanding radio amateurs who wish to have a power supply in the station protected from overload and accidental shorts. It is equipped with a low ripple circuit that provides a max current of 30A (25A standard). Lightweight, small and elegant, with a die-cast light alloy design, it includes a ripple adjustment control created by a circuit that shifts the switching frequency, to the point of taking it, in the event of interference, outside of any permitted amateur radio band.
TECHNICAL FEATURES:
- Volt/Ampere instrument;
- Voltage adjustment from 9-15 volts;
- Noise offset adjustment;
- Lighter socket (max 10 A);
- Output terminals (up to 3A current);
- 30Amper output terminals;
- Fixed / variable voltage switch;
- Forced cooling fan
